DSD110M275 Replacement module for DSD1101S275

Description Download Product Brochure here https://www.erico.com/part.asp?part=DSD110M275 SPECIFICATIONS Part Number DSD110M275 Article Number 702566 Nominal System Voltage (Un) 220 – 240 V Max Continuous Operating Voltage (Uc) 275 VAC 350 VDC Nominal Discharge Current (In), Per Mode 5 kA 8/20 μs Max Discharge Current (Imax), Per Mode 10 kA 8/20 μs Voltage Protection Level (Up) 930 V @ 3 kA 1,300 V @ 5 kA Frequency 0 – 60 Hz Technology MOV with thermal disconnect Enclosure Material UL® 94V-0 Thermoplastic Status Indication Mechanical flag Temperature -40 to 80 °C Module Width 1 M Depth (D) 49 mm Height (H) 45 mm Width (W) 18 mm Unit Weight 0.068 kg Certifications CE Standard Packaging Quantity 1 pc UPC 78285658206 EAN-13 8711893041620
